Data / Facts
D / Diameter: 5-14mm
L1 / Total length: 85-160mm
L2 / Working length: 50-100mm
More Information
Cataloguespecial- and stone drill bits
Concrete drill bit MS5 TURBOHEAD Xpro
- Concrete drill bit with round shank
- ISO 5468
- Made of chrome-nickel-molybdenum steel, shot-peened and intermediate level hardened
- TURBOHEAD Xpro head with centering tip and innovative 4-cutting-edge concept
- MS5 flute with reinforced core
- High-temperature brazing at about 1,120ºC
- In all rotating and percussion drilling machines as well as hammer drills with three jaw chuck
- Usable in armed concrete
- For drilling plug holes
- Particularly suitable for fastenings
MS5 TURBOHEAD Xpro
Innovative X-head design with 4 cutting edges for fast and professional work. The reinforced steel resistant hammer drill bits guarantees a high drilling speed as well as low abrasion. The special head-geometry allows optimum pilot drilling and a fast removal of drilling dust as well as remarkably less friction in the drilling hole which results in less development of heat and a low power input for the machine.
MS5 helix
The MS5 flute drills considerably faster than a normal flute. It has a longer service life and reduces the swinging and torsion forces caused during the hammer drilling. Therefore no jam of drilling dust occurs. It has a faster drilling speed and transfers the impact energy in an optimal way. The reinforced core and the rounded gradual transitions offer much more breaking strength.
For use in / Application
![](/typo3temp/assets/_processed_/f/6/csm_kunststein_keil_2478721111.png)
Artificial Stone
![](/typo3temp/assets/_processed_/5/a/csm_mauerwerk_keil_b923bd99cd.png)
Masonry
![](/typo3temp/assets/_processed_/7/5/csm_naturstein_keil_452d29c0d6.png)
Natural Stone
![](/typo3temp/assets/_processed_/d/4/csm_stahlbeton_keil_30bd20cde2.png)
Reinforced Concrete
Drive / Execution / Features
![](/typo3temp/assets/_processed_/9/1/csm_pgm_keil_55f858862b.png)
PGM
![](/typo3temp/assets/_processed_/3/1/csm_vibration_keil_61c2e58811.png)
Vibrationsarm
![](/typo3temp/assets/_processed_/8/5/csm_csm_keil_9132d05cf5.png)
Zylinderschaft
